R3000-Lite
R3000-Lite
Industrial Dual-SIM 4G/LTE Router with 1 x LAN & DB9 Serial RS-232 & RS-485
The Robustel R3000-Lite is a proven industrial LTE router for metering, infrastructure, and distribution networks that demand reliable, secure IP backhaul. Dual-SIM redundancy maintains service during carrier issues, while Smart Roaming optimises network selection for roaming SIMs.
For routable access, RobustVPN presents a fixed IP on any SIM, simplifying secure remote maintenance and central monitoring. Fleet operations scale through RCMS Cloud for status, configuration, and firmware updates, with standard VPNs (IPsec, OpenVPN, GRE, L2TP, PPTP, DMVPN) and Web/CLI/SNMP management.
Crucially, R3000-Lite includes a native DB9 (RS-232) port the only Robustel router with DB9 enabling straightforward integration with legacy serial equipment without adapters or custom cabling.
Designed for harsh electrical environments, it offers wide 9–60 V DC input, over-voltage protection, high EMC immunity, and DIN-rail/panel mounting. Result: hardened connectivity and simple router management that modernises legacy assets—without changing your upstream applications.
Features
- Dual SIM redundancy for persistent 2G/3G/4G cellular network connections
- RobustOS + SDK + App
- IPsec/OpenVPN/GRE/L2TP/PPTP/DMVPN
- Management and maintenance via Web/CLI/SMS/SNMP/RobustLink Cloud
- Robust industrial design (9 to 36V DC, desktop or wall mounting or DIN rail mounting )
- Introduction
- Application
- Specification
- Download
- Get A Quote
Introduction
The Robustel Industrial Dual SIM Cellular VPN Router (R3000 Lite) is a rugged cellular router offering state-of-the-art mobile connectivity for machine to machine (M2M) applications.
R3000 Lite is a powerful router developed from RobustOS, a Robustel self-developed and Linux-based operating system which is designed to be used in Robustel devices. The RobustOS includes basic networking features and protocols providing customers with a very good user experience. Meanwhile, Robustel offers a Software Development Kit (SDK) for partners and customers to allow additional customization by using C, Python or Java. It also provides rich Apps to meet fragmented IoT market demands.
Robustel is a leading global industrial IoT/M2M hardware and solution provider. Since its establishment in 2010 in Guangzhou, China, Robustel has been focusing on designing and manufacturing industrial cellular routers, gateways, modems, cloud platforms and E2E solutions. In order to support global business in more than 100+ countries and regions, Robustel has set up local offices in Germany, Australia, the Netherlands, Japan and Hong Kong.
Available Models
| Model | Supported Frequency Bands | Certifications | Order Code | Package Contents |
|---|---|---|---|---|
| R3000-L4L ANZ + LATAM |
4G LTE FDD: B1/2/3/4/5/7/8/28 4G LTE TDD: B40 3G: B1/2/5/8 2G: B2/3/5/8 |
RCM, CRC, SUBTEL, MTC, URSEC, ANATEL |
A002500706 |
1 x R3000 Lite Router (B Code: B025712) |
| R3000-L4L Japan |
4G LTE FDD: B1/3/8/18/19/26 4G LTE TDD: B41 3G: B1/6/8/19 |
Telec, JATE | A002500703 |
1 x R3000 Lite Router (B Code: B025719) |
| R3000-L4L Global |
4G LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28 4G LTE TDD: B38/39/40/41 3G: B1/2/4/5/6/8/19 2G: B2/3/5/8 |
CE, UKCA, CB, TDRA, RCM |
A002500702 |
1 x R3000 Lite Router (B Code: B025718) |
| R3000-L4L EMEA + SE Asia |
4G LTE FDD: B1/B3/B7/B8/B20/B28A 3G: B1/B8 2G: B3/B8 |
CE, UKCA, E-Mark, IMDA, SIRIM, NTC, TDRA |
A002500704 |
1 x R3000 Lite Router (B Code: B025720) |
| R3000-L4L EMEA + SE Asia |
4G LTE FDD: B1/B3/B5/B7/B8/B20 4G LTE TDD: B38/B40/B41 3G: B1/B5/B8 2G: B3/B8 |
CE, UKCA, CB | A002500705 |
1 x R3000 Lite Router (B Code: B025717) |
Application
Specification
System Architecture
| Operating System | RobustOS |
|---|---|
| CPU | ARM, 400 MHz |
| RAM | 128MB |
| Flash | 256MB |
Cellular
| Supported Technologies | 4G/LTE, 3G, 2G |
|---|---|
| Antennas | 2 (MAIN + DIV) |
| Connector | SMA-K |
| SIM | 2 x Mini SIM (2FF) |
Ethernet
| Ethernet Ports | 1 x 10/100 Mbps LAN |
|---|---|
| Magnet Isolation Protection | 1.5 KV |
Serial Port
| Serial Ports | 1 x RS-232 + 1 x RS-485 |
|---|---|
| Connector | DB9, female |
| Baud Rate | 300 bps ~ 230400 bps |
| Flow Control | RTS/CTS (for RS-232) |
Other Interfaces
| Other Interfaces | 1 x RST |
|---|---|
| LED Indicators | 1 x RUN, 1 x USR, 1 x PPP, 3 x RSSI |
| USB | 1 x USB 2.0 host, up to 480 Mbps |
| Watchdog | Built-in |
Power Supply & Consumption
| PSU Connector | 3.5 mm terminal block |
|---|---|
| Input Voltage | 12/24 V DC, 9 ~ 36 V DC Reverse polarity protection, surge protection |
| Power Consumption | Idle: 1.5 W@12 V Max: 5 W@12 V |
| Recommended Power Supply | 12 V DC/1.5 A power adapter |
Physical Characteristics
| Ingress Protection | IP30 |
|---|---|
| Housing & Weight | Metal, 305g |
| Dimensions | 29.5 x 98 x 105 mm |
| Installation Options | Desktop, Wall Mount and 35mm DIN Rail |
| Operating Temperature | -40 – +75 °C |
| Storage Temperature | -40 – +85 °C |
| Relative Humidity | 5 – 95% RH (non-condensing) |
Software Features
| Network Protocols | PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, NTP, SMTP, Telnet, ARP, VLAN, SSH2, DDNS, etc. |
|---|---|
| VPN Tunnels | IPsec, OpenVPN, GRE, WireGuard |
| Firewalls | DMZ, anti-DDoS, Filtering (IP/Domain name/MAC address), Port Mapping, Access Control |
| Remote Management | RCMS, Web, CLI, SMS |
| Serial Port Protocols | Transparent, TCP Client/Server, UDP, Modbus RTU to TCP |
| SIM Management | Smart Roaming |
| Optional Apps | L2TP, PPTP, DMVPN, VRRP, QoS, SNMP, Language, RCMS, Dynamic Route, Captive Portal, Modbus Master, TR069, Edge2Cloud, etc. |
Software Development Kit (SDK)
| Supported Programming Languages | C, C++ |
|---|---|
| Flash available for SDK | 64MB |
| RAM available for SDK | 64MB |
Regulatory and Type Approvals
| Environmental | RoHS 2.0, WEEE |
|---|---|
| EMI |
EN 55032 Conducted Emission Class B EN 55032 Radiated Emission Class B |
| EMS |
EN 61000-4-2 (ESD) Contact Level 2, Air Level 3 EN 61000-4-3 (RS) Level 2 EN 61000-4-4 (EFT) Level 2 EN 61000-4-5 (Surge) Level 3 EN 61000-4-6 (CS) Level 2 |
