M58E
M58E
3G/4G USB modem
Nimbus 3G/4G USB modem, intelligent power supply design, passed EMC tests, supportdial-up internet access, sending and receiving SMS in English, CSD data transmission and other functions; offer industrial users a stable 3G/4G network, widely used in power meter, oil monitor, environment protection, LED, POS terminals, and other areas.
Features
- Embedded with industrial 3G/4G module
- Support SMS.
- Support APN.
- Support CSD.
- Support point-to-point data transmission.
- Standard AT commands
- Windows XP, WIN7/8/10/CE, Mac OS, Linux
- Volume: L*W*H:98*68*24mm
- Weight:200g
- Safety Glass: IP30
- Storage temperature:- 40℃~85℃Work
- Temperature:-30℃~65℃
- Humidity:<95%
- Introduction
- Application
- Specification
- Download
- Get A Quote
Introduction
Nimbus 3G/4G USB modem, intelligent power supply design, passed EMC tests, supportdial-up internet access, sending and receiving SMS in English, CSD data transmission and other functions; offer industrial users a stable 3G/4G network, widely used in power meter, oil monitor, environment protection, LED, POS terminals, and other areas.
Application
Specification
| Model | Network / Frequency | Bandwidth (UL/DL) | Consumption | Power |
|---|---|---|---|---|
| M53 | CDMA 800MHz | 1.8 Mbps / 3.1 Mbps |
Work: 0.25A @ 12V DC Peak: 0.32A @ 12V DC |
US/EU
standard Input: AC100~240V Output : DC12V Option |
| M56 |
UMTS/HSPA+ (2100/1900/900/850 MHz) GSM/GPRS/EDGE (850/900/1800/1900 MHz) |
5.76 Mbps / 21 Mbps |
Work: 0.23A @ 12V DC Peak: 0.31A @ 12V DC |
|
| M58E (Europe & Asia) |
FDD-LTE: B1, B3, B5, B7, B8, B20 UMTS/HSPA+: B1, B2, B5, B6, B8 |
LTE: 50 / 100 Mbps HSPA+: 5.76 / 42 Mbps |
Work: 0.41A @ 12V DC Peak: 0.50A @ 12V DC |
|
| M58C (China & Asia) |
FDD-LTE: B1, B3, B8 TDD-LTE: B38, B39, B40, B41 UMTS/HSPA+: B1, B5, B8, B9 TD-SCDMA: B34, B39 |
FDD: 50 / 150 Mbps TDD: 10 / 112 Mbps HSPA+: 5.76 / 42 Mbps |
Work: 0.41A @ 12V DC Peak: 0.50A @ 12V DC |
|
| M58A (America) |
FDD-LTE: B2, B4, B5, B13, B17, B25 UMTS/HSPA+: B1, B2, B4, B5, B8 |
LTE: 50 / 100 Mbps HSPA+: 5.76 / 42 Mbps |
Work: 0.41A @ 12V DC Peak: 0.50A @ 12V DC |
|
| M58J (Japan) |
FDD-LTE: B1, B3, B5, B7, B8, B18, B19, B21, B28 TDD-LTE: B38, B39, B40, B41 WCDMA: B1, B5, B6, B8, B9, B19 |
LTE: 50 / 100 Mbps HSPA+: 5.76 / 42 Mbps |
Work: 0.41A @ 12V DC Peak: 0.50A @ 12V DC |
